SOURCE Power Consumption: 520W Input Voltage: 100-240V; 50-60Hz 421W USHIO discharge lamp, 4000hrs White Light Color Temperature: 7500K±300K Working temperature: -45°C --70°C CRI>90 Power factor: PF≥0.98
OPTIC 155mm lens diameter 1.8° beam angle 8-facet circular and 8+16 facet prism Independent electronic frost filter Electronic focusing system High Speed Electronic Shutter and 0-25Hz Strobe
COLOR WHEEL 1 Color Wheel: 14 colors+ open Half Color Effect, Rainbow Effect with bi-directional and Variable Speeds Stepping/Linear Color Changing
FIXED GOBOS 1 Fixed Gobo Wheel: 15 static gobos + white Shaking at variable speed and bi-directional scrolling effect |
| DISPLAY LCD display, touch screen Investable 180° display Battery-powered display
MOVEMENT Pan/Tilt: 540°/270°; 16bit With auto position correction and adjustable speed
CONTROL/CONNECTIONS DMX Channel: 20 Channels Power Connector: Seetronic True-one input/output Single Connector: 3Pin or 5Pin DMX XLR input/output Control Mode: DMX 512 Control; Sound Control; Stand-Alone; Master/Slave
OTHER FUNCTIONS With RDM Able to update software via DMX XLR
HOUSING High-temperature-resistant engineering plastic IP rate: IP66 Fixture size: 353x260x604mm N.W.: 19kgs G.W.: 22kgs |
