SPECIFICATION
Power consumption: 500W
Input voltage: AC 90V-240v, 50-60Hz Light source: OSRAM SIRIUS HRI 382W discharge lamp CCT: 7500K Life time: 1500hrs
FEATURES Color wheels: 11 colors +Open CMY filters; optional Beam angle: 2° Display: LCD display Static gobo wheel: 15 fixed metal gabos + Open Animation disk: Water-effect gobo Prism: 16facet prism/8facet prism;optional Dimmer: 16-bit Electronic Dimmer with 4 curves With frost filter Electronic strobe: 25times/sec
Motorized Pan/Tilt Pan movement range: 540° Tilt movement range: 270°
Automatic Pan/Tilt position correction control 3-Phase step motors
CONTROL
DMX Channel: 16CH
Control mode: DMX512 control; Stand-alone; Master Slave synchronization; RDM
| CONSTRUCTION Display: LCD display Data in/out sockel: Hard-wired dmx input and output Power connector: Hard-wired power input and output Protection rate: IP65; Housing; heal-proor plastic+ module pressing alloy material. Black/ silver/ white color, optional Cooling System: Automatic over-heat protection system;ideal cooling operation
PHYSICAL
Unit Dimensions: 418(L)*378(W)*620(H)mm Packing Dimension: 725x465x500mm/pc Packing Dimension: 500x435x830mm/flight case/1pc Packing Dimension: 925x515x830mm/flight case/2pcs
Unit Net Weight: 25kg Gross Weight: 44kg/1pc/case Gross Weight: 82kgs/2pcs/case
MISCIOPTIONS Power cable: included Mounting camp: included Safety cable: included 1in1/2in1 Flight case: optional |
